Drive Axle for Forklifts

Drive Axle for Forklifts - The piece of equipment that is elastically affixed to the framework of the vehicle using a lift mast is known as the lift truck drive axle. The lift mast connects to the drive axle and could be inclined, by at least one tilting cylinder, round the axial centerline of the drive axle. Frontward bearing components together with rear bearing parts of a torque bearing system are responsible for fastening the vehicle and the drive axle frame. The drive axle can be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the back bearing elements. The lift mast could likewise be inclined relative to the drive axle. The tilting cylinder is affixed to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented practically parallel to a plane extending from the axial centerline and to the swiveling axis.

Forklift units like H35, H40 and H45 that are made in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably mounted on the vehicle framework. The drive axle is elastically affixed to the lift truck frame by a multitude of bearing devices. The drive axle contains a tubular axle body together with extension arms connected to it and extend backwards. This type of drive axle is elastically attached to the vehicle frame using back bearing elements on the extension arms along with forward bearing tools situated on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing machine in its respective pair.

The drive and braking torques of the drive axle on this unit of lift truck are sustained by the extension arms through the back bearing parts on the frame. The forces produced by the lift mast and the load being carried are transmitted into the floor or road by the vehicle frame through the front bearing elements of the drive axle. It is vital to be sure the parts of the drive axle are constructed in a firm enough method to maintain stability of the forklift truck. The bearing elements could minimize minor bumps or road surface irregularities during travel to a limited extent and provide a bit smoother function.
